# API Client Registration

{% hint style="success" %}
*Check out the given illustration to understand the API Client Registration functionality.*
{% endhint %}

<figure><img src="https://859511478-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FGDmsjfjJBNqow7Fo97cO%2Fuploads%2FDkKB5OP99odgy6b4zcVw%2FClientRegistration.gif?alt=media&#x26;token=746f1535-fe90-4199-9920-c8a6da0b3851" alt=""><figcaption></figcaption></figure>

The API Client Registration option helps the user to register and save the specific details of API Clients. The API Client Registration form requires a specific data set link published as a service to complete the registration process.

## Registering an API Client

* Navigate to the ***Admin Module.***
* Click the **API Client Registration** option from the side navigation bar.​

<figure><img src="/files/pvwjEayhhbCCOIrvyPBi" alt=""><figcaption></figcaption></figure>

* The ***API Client Registration*** ***page*** opens.
* Click the ***New*** option to create new client registration.

<figure><img src="/files/hK5tOFve7QMBpm5MwaKm" alt=""><figcaption></figcaption></figure>

* There are two **Authentication** types available to be selected by the user: **Internal** or **External** (The user can select any one of them).

<figure><img src="/files/KfWKZnrWnkyvBpOAlYe8" alt=""><figcaption></figcaption></figure>

### Internal Client Registration <a href="#internal-client-registration" id="internal-client-registration"></a>

If **Internal** option is selected **Authentication** will happen from the platform side by using client id, client secret & app name.

* Select ***Internal*** as the authentication option.
* Provide the following information:
  * Client Name
  * Client Email
  * App Name
  * Request Per Hour
  * Request Per Day
  * Select API Type: Select either of the options: ***Data as API*** or ***Model as API***

{% hint style="info" %}
*<mark style="color:green;">Please Note</mark><mark style="color:green;">:</mark> Select API Type: The user can select any one of the given choices. Both **Data as API** & **Model as API** support Internal Authentication. So the user needs to select either one of them in **Select API Type**.​*
{% endhint %}

* After selecting one option from the ***Select API Type***, the ***Select the Services Entitled*** field appears (The user can select multiple ***Data as API*** or ***Model as API*** option by using this field) E.g., In the given image the ***Data As API*** option has been selected, so the ***Select the Services Entitled*** field displays available ***Data as APIs*** in the given drop-down menu.
* Click the ***Save*** option.

<figure><img src="/files/e36E4TbE6uwKteFMj03s" alt=""><figcaption></figcaption></figure>

* A notification message appears.
* The created API Client gets listed at the top of the displayed ***Client List***.

<figure><img src="/files/ws3QYY6DqTs3tqcrkZBH" alt=""><figcaption></figcaption></figure>

{% hint style="info" %}
*<mark style="color:green;">Please Note:</mark>*

* *The **client id** and **client secret** will be automatically generated by the platform while saving the **API Client Registration**.*
* *Both **Data as API** & **Model as API** support Internal Authentication. So the user needs to select either one of them in **Select API Type**.*
  {% endhint %}

### External Client Registration  <a href="#external-client-registration" id="external-client-registration"></a>

The **External** option does not support **Authentication** by using client id, client secret, and app name. The user needs to authenticate by providing the secret Key and Values/Mapping key. The authentication will consider only if the selected ***Validation Type*** is ***Validated.***

* Select the ***External*** option.
* Provide the following details:
  * Client Name
  * Client Email
  * Select the entitled services from the drop-down menu.
* Provide Key, Validation Type and Value/Mapping Key.
* Click the ***Save*** option.

<figure><img src="/files/QOJgkkWThMrEyM4htgT6" alt=""><figcaption></figcaption></figure>

{% hint style="info" %}
*<mark style="color:green;">Please Note:</mark>* *The **Select the Services Entitled** will display the data sets published as service* *from the **Data Center** module of the platform.*
{% endhint %}

* A notification message appears.
* The ***API Client*** details get saved at the top of the displayed ***Client List.***

<figure><img src="/files/mZrGxPKtrVhnt5vTCaOg" alt=""><figcaption></figcaption></figure>

## **How to call the API from POSTMAN**  <a href="#how-to-call-the-api-from-postman" id="how-to-call-the-api-from-postman"></a>

### **Internal Authentication API** <a href="#how-to-call-the-api-from-postman" id="how-to-call-the-api-from-postman"></a>

* Click the ***Edit*** option for the saved API Client Registration.
* The API Client Registration form reopens.
* The user can get the ***Client Id***, ***Client Secret***, and ***App Name***.

<figure><img src="/files/XR5Qi8pxI0O4IPTgxt0d" alt=""><figcaption></figcaption></figure>

* Pass the ***Client id, Client Secret Key,*** and ***App Name*** in the ***Postman GET/ POST*** call to get the response.

<figure><img src="/files/J0SuBff6v7oUtCGjXU4R" alt=""><figcaption></figcaption></figure>

### **External Authentication API**

* Click on the ***Edit*** option for the saved External API Client.
* The API Client Registration form reopens.
* Select the entitled Service.
* The user can get the following information about the API Service:

  * Key
  * Validation Type
  * Value/ Mapping Key

  &#x20;    &#x20;

  <figure><img src="/files/F4oc1SsjsXGQsr3mEqU4" alt=""><figcaption></figcaption></figure>
* Pass the mapping key value in the ***Postman GET/POST*** call to get the response.

<figure><img src="/files/BeNIIHghbR2l98RhaHNq" alt=""><figcaption></figcaption></figure>


---
